Installation
13 F232228
Floor Load Data
† Acting in the downward direction against the floor.
†† Acting in the upward direction against the floor.
UW A-Control, Variable Speed Pocket Hardmount
Specifications UW35AV 160g UW60AV 160g UW80AV 160g UW100AV 160g UW125AV 160g
Static Load Pressure, kN/sq m 6.33 7.77 8.46 9.18 9.16
Static Load Pressure, lbs/sq ft 132 162 177 192 191
Total Dynamic Load, kN* 5.0 8.6 11.4 14.2 17.8
Total Dynamic Load, lbs* 1122 1922 2562 3203 3996
Dynamic Load Pressure, kN/sq m 7.1 10.3 9.8 12.3 11.9
Dynamic Load Pressure, lbs/sq ft 149 216 205 256 249
Dynamic Load Freq, Hz 10.9 9.9 9.3 9.3 8.6
Maximum Vertical Load, kN† 8.5 13.7 19.1 22.3 28.3
Maximum Vertical Load, lbs† 1917 3073 3073 5002 6358
Minimum Vertical Load, kN†† 1.45 3.43 3.43 6.24 7.27
Minimum Vertical Load, lbs†† 326.62 770.90 823.07 1403.64 1634.52
Maximum Moment about Machine Base,
kN-m 3.9 8.2 11.3 14.1 18.0
Maximum Moment about Machine Base,
lb-ft 2893 6053 8322 10,403 13,243
Table 2
