Installation
F232228 8
.
UWAV Pocket Hardmount General Specifications
Specifications 35 60 80 100 125
Overall Dimensions
Overall width, in (mm) 32.5 (826) 36.625 (930) 41.5 (1054) 41.5 (1054) 48 (1219)
Overall height, in (mm) 55.5 (1410) 64.5 (1638) 68.5 (1740) 68.5 (1740) 72 (1829)
Overall depth, in (mm) 43.625 (1108) 45 (1143) 51.5 (1308) 54.5 (1384) 58 (1473)
Weight and Shipping Information
Net weight, lb (kg) 750 (341) 1229 (559) 1640 (744) 1680 (762) 2211 (1005)
Domestic shipping weight, lb (kg) 800 (361) 1268 (575) 1705 (773) 1745 (792) 2525 (1148)
Domestic shipping volume, ft 3 (m 3 ) 66 (1.9) 84 (2.4) 119 (3.4) 119 (3.4) 166 (4.7)
Domestic shipping dimensions,
WxDxH, in (mm) 38x47x64
(970x1200x1630)
40x49x74.5
(1016x1245x1892)
44x60.5x77.25
(1118x1537x1962)
44x60.5x77.25
(1118x1537x1962)
61.5x60x77.75
(1560x1520x1980)
Export shipping weight, lb (kg) 910 (413) 1392 (631) 1900 (863) 1940 (881) 2591 (1178)
Export shipping volume, ft 3 (m 3 ) 78 (2.2) 96 (2.7) 134 (3.8) 134 (3.8) 184 (5.3)
Export shipping dimensions,
WxDxH, in (mm) 41x50x65.5
(1050x1280x1670)
43x52x72.5
(1092x1324x1892)
47x63.5x76
(1194x1613x1962)
47x63.5x76
(1194x1613x1962)
59x63x80
(1620x1610x2030)
Wash Cylinder Information
Cylinder diameter, in (mm) 26.25 (667) 32 (813) 36 (914) 36 (914) 42 (1067)
Cylinder depth, in (mm) 18.375 (467) 20 (508) 21 (533) 27 (686) 24 (610)
Cylinder volume, ft 3 (l) 5.76 (163) 9.31 (264) 12.4 (350) 15.9 (450) 19.2 (544)
Perforation size, in (mm) .1875 (4.8) .1875 (4.8) .1875 (4.8) .1875 (4.8) .1875 (4.8)
Perforation open area, % 18 22 23 23 24
Door Opening Information
Door opening size, in (mm) 14.375 (365) 17.5 (445) 17.5 (445) 17.5 (445) 20 (508)
Height of door bottom above floor,
in (mm)
23.75 (603) 28.25 (718) 29 (737) 29 (737) 29 (737)
Water Consumption
Average water
consumption per
cycle, gal (l) HOT 45 (170) 61 (231) 90 (341) 106 (401) 114 (431)
COLD 24 (91) 29 (110) 41 (155) 47 (178) 52 (197)
Average hot water used per hour, gal (l) 78 (295) 102 (386) 139 (526) 161 (609) 168 (636)
Power Consumption
Average power used per cycle, kW/hr 0.18 0.28 0.40 0.40 0.48
Average HVAC load, BTU/hr (kcal/hr) 800 (202) 950 (240) 1050 (265) 1150 (290) 1200 (302)
