Drive Train Information

Number of motors in drive train

Drive motor power, hp (kW)

2.3 (1.7)

2.9 (2.2)

5.0 (3.7)

7.5 (5.6)

Cylinder Speeds / Centrifugal Force Data

1/2 Wash/reverse, rpm (g)

26 (.25)

26 (.31)

26 (.35)

26 (.40)

Wash/reverse, rpm (g)

42 (.66)

40 (.73)

40 (.82)

37 (.82)

Distribution, rpm (g)

83 (2.57)

71 (2.29)

73 (2.57)

70 (2.50)

62 (2.29)

High extract 1, rpm (g)

328 (40)

297 (40)

280 (40)

260 (40)

High extract 2, rpm (g)

534 (106)

483 (106)

456 (106)

422 (106)

High extract 3, rpm (g)

656 (160)

594 (160)

560 (160)

518 (160)

Balance Detection

Vibration safety switch installed

N/A

STD

Safety switch gap setting, in (mm)*

N/A

.008 (.20) GO

.010 (.25) NO-GO

.008 (.20) GO

.010 (.25) NO-GO

.008 (.20) GO

.010 (.25) NO-GO

.006 (.15) GO

.008 (.20) NO-GO

Direct Steam Heating (Optional)

Steam inlet connection size, in

.75

Number of steam inlets

Steam required to
raise bath
temperature
10°F, lb (10°C, kg)

LOW

2.1 (1.5)

3.3 (2.4)

4.6 (3.3)

5.7 (4.1)

6.7 (4.9)

MED

2.3 (1.7)

3.7 (2.6)

5.2 (3.8)

6.5 (4.7)

7.8 (5.6)

HIGH

2.7 (1.9)

4.1 (2.9)

6.1 (4.4)

7.6 (5.5)

9.1 (6.6)

Average consumption per cycle, bhp (kg)

1.4 (21.4)

2.1 (33.4)

3.1 (48.4)

3.8 (60.4)

4.6 (72.0)

Electrical Heating (Optional)

Total electrical heating capacity, kW

15.6

25.2

37.8

50.4

Number of electrical heating elements

Electrical heating element size, kW

2.6

4.2

Time required to
raise bath
temperature
10°F, min (10°C,
min)

LOW

2.4 (3.6)

2.4 (3.7)

2.2 (3.4)

2.8 (4.2)

2.5 (3.8)

MED

2.7 (4.1)

2.5 (3.9)

3.2 (4.8)

2.9 (4.4)

HIGH

3.1 (4.7)

3.0 (4.6)

3.0 (4.5)

3.7 (5.6)

3.4 (5.1)

* Gap setting should be made with “GO-NO-GO” type feeler gauge.

UWAV Pocket Hardmount General Specifications (Continued)
