Packing List
Check-marked for applicable model and content
Intel  Pentium 4 socket 478 AMD  Duron, Athlon, MP, XP socket 462
Intel  Pentium 4 socket LGA775 AMD  Athlon 64 & Opteron
Intel  Xeon  Processor, socket 603/604
Intel  Xeon  “Nocona” Processor, 800Mhx FSB, socket
604 Bare kit without water-block
Qty Item Incl Qty Item Incl
1 MCW6000-A  CPU water-block for
AMD  K7 processors (Duron  ,
Athlon  MP and XP), 2’each pre-
installed inlet/outlet tubing
1 MCR80-F2  radiator assy. incl. (1) Radiator,
(1) 80x80x25mm fan, (1) fan guard, (4) #6 x 1
¼” screws, (4) #6 x 3/8” screws, (2) 7/32-5/8”
quick-connect fittings
D
1 MCW6000-64  CPU water-block
for AMD  K8 processors (Athlon 
64 and Opteron), 2’each pre-
installed inlet/outlet tubing
1 Additional MCR80-F2  radiator assy. incl. (1)
Radiator, (1) 80x80x25mm fan, (1) fan guard,
(4) #6 x 1 ¼” screws, (4) #6 x 3/8” screws, (2)
7/32-5/8” quick-connect fittings
1 MCW6000-P  CPU water-block for
Intel  Pentium  4 processors,
2’each pre-installed inlet/outlet
tubing
1 MCP650  12 Volts DC industrial pump with
retention screws, 1 ½ ft pre-installed inlet tubing
(½” ID), pre-installed 3/8” discharge barb
adapter
D
1 MCW6000-775  CPU water-block
for Intel  Pentium  4 LGA775
processors, 2’each pre-installed
inlet/outlet tubing
1 MCRES-525  incl. (1) reservoir, (1) 1/2” barb,
(1) 3/8” barb, (1) port plug, (1) fill-cap, (4)
screws
D
1 MCW6000-PX  CPU water-block
for Intel  Xeon  processors,
2’each pre-installed inlet/outlet
tubing
1 40” length Coolsleeves  clear coils D
2 MCW6000-NX  CPU water-block
for Intel  Xeon  “Nocona”
processors, 2’each pre-installed
inlet/outlet tubing
4 Feet ½” OD high quality vinyl tubing D
1 MCW50 VGA cooler 1 2 oz bottle HydrX  specially formulated coolant D
1 MCW20-R chipset cooler
