Installation
Oven Assembly
PACKAGING
Before beginning assembly and installation of the oven,
check that all necessary components have been received.
In addition to the oven itself, legs, the proper vent, and/or
other accessories may be required.
Single Sections
1060 with Steel Deck
• Legs, regulator, set of flue plates, draft diverter and
steel deck are shipped in the oven.
• Drafthood (when supplied) is packed separately.
1060 with Ultra Rokite Decks
• Legs, regulator, set of flue plates and draft diverter
are shipped in oven.
• Ultra Rokite decks are packed in a separate carton.
• Drafthood (when supplied) is packed separately.
Double Sections
1060 with Steel Deck
• Legs and bolts, regulator, set of flue plates and steel
deck are packed in the lower section.
• Regulator, set of flue plates, draft diverter and steel
deck are packed in the upper section.
• Crown angle leg frame is packed in a separate
carton.
• Drafthood (when supplied) is packed in a separate
carton.
1060 with Ultra Rokite Decks
• Legs and bolts, regulator, set of flue plates are
packed in the lower section.
• Regulator, draft diverter and a set of flue plates are
packed in the upper section.
• Ultra Rokite decks are packed in two separate car-
tons.
• Crown angle leg frame is packed in a separate
carton.
• Drafthood (when supplied) is packed in a separate
carton.
LEG ATTACHMENT
1. Put the oven onto a genie lift with the bottom of the
oven down. Be careful not to damage the louvered
panel under the oven.
2. Each leg is attached by three bolts to the underside of
the oven base frame.
CASTER ATTACHMENT
1. Bolt supports to oven with 1/2-13 hex head bolts
(casters with brakes should be facing front of oven.)
2. Carefully place oven onto the casters. (It will be nec-
essary to have several persons lift oven off the pallet
and set it onto the casters). Engage brakes on front
casters.
NOTE: A fixed restraint must be provided if casters are
used in conjunction with a flexible connector for
movable appliances. This restraint must secure
the oven to a non-movable surface to eliminate
stress on the connector. If the oven is moved, the
restraint must be reconnected after the oven is
returned to it’s normal position.
