Allied Telesis AT-PBC18 User Manual
Page 32
22
The PowerBlade Optional Power Modules are available in two models,
AT-PBPWRAC for an AC powered chassis and AT-PBPWRDC for a DC
powered chassis. Figure 15 and Figure 16 illustrate the two different power
supply modules.
Figure 15 AT-PBPWRAC Power Supply Module
Figure 16 AT-PBPWRDC Power Supply Module
PBPWRAC
AC INPUT
100-240AC
50-60Hz
3A MAX.
150W
AC Connector
Power LED
PBPWRDC
FOR CENTRALIZED DC
POWER CONNECTION,
INSTALL ONLY IN A
RESTRICTED AREA
36-60VDC , 1.0A
DC INPUT
DC Terminal
Power LED
Block
