Appendix A

AT-MR908TX Specifications

Physical Characteristics

Dimensions:

14.2” x 6.7” x 1.8”

Operating temperatures:

to 50

Storage temperatures:

-10

to 70

Relative humidity:

5% to 80% (non-condensing)

Operating altitude:

Up to 10,000 ft.

Desktop mounting:

4 ea. adhesive plastic feet attached to

the bottom of the hub

Note

You must remove the center pin in each foot before you are able to
remove the foot itself. Removing the center pin can be accomplished by
simply prying out the pin with a screwdriver blade and, subsequently,
using the screwdriver blade to separate the foot from the chassis.

Electrical and Mechanical Features

Standard:

IEEE 802.3u, 100BASE-TX Class I and II
unmanaged hub

Network Ports:

100BASE-TX ports for Fast Ethernet

with shielded RJ-45 connectors

Cooling:

Internal fan with left and right side air-intake
vents
