Figure11: a stacked/cascaded installation – Allied Telesis AT-MR908TX User Manual
Page 39

AT-MR908TX Installation Manual
19
Second, you are referred to the information previously presented on cascading.
This process will, in turn, allow you to electronically combine the two separate
stacks of hubs into a single network or collision domain.
Combining this information will result in a stacked/cascaded installation as
shown in Figure 11. For simplicity, only two hubs are shown in each stack.
Additionally, we recommend that cascading be performed using the bottom
most hubs to mitigate internal propagation delays.
Figure 11: A Stacked/Cascaded Installation
Port 2
(hub B)
Port 1
(hub A)
MDI/MDI-X
switch set
to MDI
