Chapter 21: Spanning Tree and Rapid Spanning Tree Protocols
424 Section V: Spanning Tree Protocols
The STP Port Parameters menu is shown in Figure 146.
Figure 146. STP Port Parameters Menu
4. Type 1 to select Configure STP Port Settings.
The following prompt is displayed:
Start Port to Configure [1 to 26] ->
5. Enter the number of the port you want to configure. To configure a
range of ports, enter the first port of the range.
The following prompt is displayed:
End Port to Configure [1 to 24] ->
6. To configure just one port, enter the same port number here as you
entered in the previous step. To configure a range of ports, enter the
last port of the range.
The Configure STP Port Settings menu is shown in Figure 147.
Figure 147. Configure STP Port Settings Menu
7. Adjust the following parameters as needed.
Allied Telesis AT-9424T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
STP Port Parameters
1 - Configure STP Port Settings
2 - Display STP Port Configuration
R - Return to Previous Menu
Enter your selection?
Allied Telesis AT-9424T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Configure STP Port Settings
Configuring Ports 4-6
1 - Port Priority ..... 128
2 - Port Cost ......... Automatic-Update
R - Return to Previous Menu
Enter your selection?
