AT-MCR1 Media Converter Chassis Installation Guide
29
Mounting the Chassis on the Wall
The chassis can be mounted vertically on a wall using the
mounting brackets that come with the unit.
To mount an AT-MCR1 chassis on the wall, perform the following
procedure:
1. If attached, remove the rubber feet and power cord from the
chassis.
2. Select a wall location for the chassis and mark two hole
locations for the wall-mounting screws or plastic wall anchors
(for wall-mounting onto a concrete wall).
Note
Make sure that the location provides easy access for
installing the twisted pair, fiber optic, and power cables to and
from the chassis.
Note
If the AT-MCR1 is to be mounted onto a concrete wall, make
sure to drill the required holes with the drill bit using the drill
bit size that is suitable for the plastic wall anchors. Then,
insert the plastic wall anchors.
Caution
The attached mounting brackets must be used to securely
mount the chassis onto the wall.
