Installing a media converter in the chassis – Allied Telesis AT-MCR1 User Manual
Page 22
Chapter 2: Installation
22
Installing a Media Converter in the Chassis
To install a media converter in the AT-MCR1 chassis, perform the
following procedure:
1.
Remove all components from the shipping packages.
Note
Store the packaging material in a safe place. You must use
the original shipping material if you need to return the unit to
Allied Telesis.
2.
Loosen the captive screw on the mounting rail and remove it
from the chassis, as shown in Figure 3.
Figure 3. Removing the Mounting Rail from the Chassis
1048
PW
R
AT
-MCR1
