Chapter 1, Overview, Chap – Allied Telesis AT-MCR1 User Manual
Page 13
13
Chapter 1
Overview
The AT-MCR1, shown in Figure 1, is a chassis with an internal
power supply designed to house one Allied Telesis media
converter. The AT-MCR1 chassis provides convenient installation
options: on a desktop, mounted under a table, placed on the wall,
or installed in an industry standard 19” or 23” rack.
Figure 1. AT-MCR1 Media Converter Chassis
The AT-MCR1 chassis includes a mounting rail (750-10857-00),
as shown in Figure 2, for installing a media converter.
Figure 2. Mounting Rail
1046
PWR
AT-MCR1
1047
