Allied Telesis AT-iMG646PX-ON - Manual (Page 89)

89
Appendix A
Technical Specifications
Physical Specifications
Dimensions: AT-EN646 330 mm x 230.7 mm x 43.2 mm
(12.99 in x 9.08 in x 1.7 in)
AT-iMG646BD-ON 305 mm x 218 mm x 25 mm
(12.0 in x 8.6 in x 1.0 in)
AT-iMG646PX-ON 305 mm x 218 mm x 25 mm
(12.0 in x 8.6 in x 1.0 in)
Weight: AT-EN646 2.38 kg (5.25 lbs)
AT-iMG646BD-ON 1.23 kg (2.7 lbs)
AT-iMG646PX-ON 1.23 kg (2.7 lbs)
Environmental Specifications
Operating Temperature: -40° C to 60° C (-40° F to 140° F)
Storage Temperature: -40° C to 70° C (-4° F to 158° F)
Operating Humidity: 5% to 90% non-condensing
Storage Humidity: 5% to 95% non-condensing
Operating Altitude Range: Up to 3,000 m (9,843 ft)
Power Specifications
Input Supply Voltage: 12 V DC
Power Consumption:10W typical, 18W max
Safety and Electromagnetic Emissions Certifications
EMI/RFI: FCC Class B, EN55022 Class B,
