Chapter 5: Installing the Gateway Indoors
82
Section II: Indoor Installation
Connecting the Telephone Wires
To connect the telephone wires, perform the following procedure:
1. Connect the telephone wires to each pair of telephone terminal posts
on the gateway, as shown in Figure 54.
Figure 54. Connecting the Telephone Wires
1177
