AT-PC232/POE Media Converter Installation Guide
55
Table 12 lists the RJ-45 port pin signals when a twisted pair port is
operating in the MDI-X configuration at 10 or 100 Mbps.
100Base-FX Port Specifications
Table 13 lists the operating specifications for fiber port (Port 1) .
Table 2. MDI-X Pin Signals (10/100Base-TX)
Pin Signal
1 RX+
2 RX-
3 TX+
6 TX-
Table 3. 100Base-FX Port 1 Specifications
Property Value
General
Maximum Distance 2 km
Fiber Optic Cable 50/125 µm or 62.5/125 µm (core
cladding) multimode fiber optic cable
Transmitter Characteristics
Wavelength 1310 nm
Output Power
Min: -22.5 dBm
Typical: -20.3 dBm
Max: -14 dBm
Receiver Characteristics
Wavelength 1310 nm
Input Power
Min: -31.8 dBm
Typical: -34.5 dBm
Max (Saturation): -14 dBm
Max Power / Link Budget 9.3 dB (62.5/125 µm cabling)
12.8 dB (50/125 µm cabling)
Fiber Optic
Typical Loss Factor 1.00 dB (62.5/125 µm cabling)
1.00 dB (50/125 µm cabling)
Connector Type Duplex SC
