AT-PC232/POE Media Converter Installation Guide
27
10/100Base-TX
Twisted Pair Port
LEDs
the LEDs for the 10/100Base-TX twisted pair port defined in Table 4,
“Twisted Pair Port LEDs” page 27.
100Base-FX
Fiber Optic Port
LEDs
The two LEDs for the are defined in Table 5.
Table 4. Twisted Pair Port LEDs
LED Color Description
LINK
Green A valid link has been established on the port.
Blinking
Green Indicates that when the AT-PC232/POE Media
Converter is in SML mode, the LINK on the
100BASE-FX port is lost.
Off A port has not established a link with an end node.
ACT
Blinking
Green Indicates that the port is transmitting and/or
receiving data packets.
Off Indicates that there is no activity on the port.
100
Green Indicates that the port is operating at 100 Mbps.
OFF *With the LINK LED either Green or Blinking
Green:
Indicates that the port is operating at
10 Mbps.
AUTO
NEG Green Indicates that Auto-Negotiation is ON.
Off Indicates that Auto-Negotiation is OFF.
Table 5. Fiber Optic Port LEDs
LED Color Description
LINK
Green Indicates a valid link has been established
between the port and the end-node.
Blinking
Green Indicates that when the AT-PC232/POE Media
Converter is in SML mode, the LINK on the
100BASE-TX port is lost.
Off Indicates that there is no link between the port
and the end-node.
ACT
Blinking
Green Indicates that the port is transmitting and/or
receiving data packets.
Off Indicates that there is no activity on the port.
