Chapter 2: Installation
40
Wall-Mount Installation
The AT-PC232/POE Media Converter can be mounted vertically on a wall
using the keyholes on the bottom of the switch. Two plastic anchors and
screws necessary to mount the switch on a wall are provided in the
accessory kit.
To wall-mount the switch, perform the following procedure:
1. If attached, remove the rubber feet, data cables, and power cord from
the switch.
2. Select a wall location for the switch.
3. Install two plastic anchors and two screws into the wall so that they are
level with each other and spaced 64 mm (2.52 in) apart.
4. Position the switch onto the wall screws, as illustrated in Figure 7.
Figure 7. Positioning the Switch onto the Wall Screws
