Chapter 1: Overview
16
Introduction
The AT-PC232/POE Media Converter is a 10/100Base-TX copper to
100Base-FX fiber media converter is designed for both standalone and
wall mount use and does not require software configuration or
management.
Figure 1 illustrates the front panel of the AT-PC232/POE Media Converter.
Figure 1. AT-PC232/POE Front Panel
Figure 2 illustrates the back panel of the AT-PC232/POE Media
Converter.
Figure 2. AT-PC232/POE Back Panel
1356
1 2 3 4
10
100
SPEED
(Mbps)
OFF
ON
AUTO
NEG
HALF
FULL
DUPLEX
MODE
2
PORT
1 2 2
100-240VAC ~
1357
