AT-PC2002/POE Media Converter Installation Guide
61
Table 13 lists the RJ-45 port pin signals when the port is operating in the
MDI-X configuration at 10 or 100 Mbps.
Table 14 lists the pin signals when the twisted pair port is operating at
1000 Mbps.
Table 13. MDI-X Pin Signals (10 or 100 Mbps)
Pin Signal
1 RX+
2 RX-
3 TX+
6 TX-
Table 14. Pin Signals - 1000 Mbps
Pinout Pair
1 Pair 1 +
2 Pair 1 -
3 Pair 2 +
4 Pair 3 +
5 Pair 3 -
6 Pair 2 -
7 Pair 4 +
8 Pair 4 -
