Chapter 1: Overview
28
SFP Module Slot
LEDs
The LEDs for the SFP module slot are described in Table 5.
For additional information on the Link LED, refer to “Link LEDs and the
Operating Modes” on page 29.
Operating Mode
LEDs
The three LEDs to the right of the Mode button display the media
converter’s operating mode and are defined in Table 6.
Table 5. SFP Transceiver Slot LEDs
LED
Color
Description
LINK
Green
The port on the SFP transceiver has established
a link to a network device.
Blinking
Green
The media converter is operating in the Smart
MissingLink mode and there is no connection on
the twisted pair port.
Off
The port has not established a link with a network
device.
ACT
Blinking
Green
The port is transmitting and/or receiving network
packets.
Off
The port is not transmitting and/or receiving
network packets.
100
Green
The port is operating at 100 Mbps.
1000
Green
The port is operating at 1 Gbps.
Table 6. Operating Mode LEDs
LED
Color
Description
ML
Green
The media converter is in the MissingLink
mode.
SML
Green
The media converter is in the Smart
MissingLink mode.
LT
Green
The media converter is in the Link Test
mode.
