10/100/1000Base-
T Twisted Pair
Port LEDs
The LEDs for the 10/100/1000Base-T twisted pair port are described in
Table 4.
For additional information on the Link LED, refer to “Link LEDs and the
Operating Modes” on page 29.
Table 4. 10/100/1000Base-T Twisted Pair Port LEDs
LED Color Description
LINK Green The port has established a link to a
network device.
Blinking Green The media converter is operating in the
Smart MissingLink mode and there is no
connection on the port on the SFP
module.
Off The port has not established a link to a
network device.
ACT Blinking Green The port is transmitting and/or receiving
network packets.
Off The port is not transmitting and/or
receiving network packets.
10
100 10 -Green The port is operating at 10 Mbps.
100 - Off
10 - Off The port is operating at 100 Mbps.
100 - Green
10 - Green The port is operating at 1 Gbps.
100 - Green
PoE Green The twisted pair port is connected to a
powered device and is providing power to
the device.
Off The twisted pair port is not supplying
power to the network device connected to
the port.
ANeg Green The port is using Auto-Negotiation to
control its speed and duplex mode.
Off The speed and duplex mode on the port
are set manually.
