Figure 10. mounting the switch on the rack – Allied Telesis AT-GS950/48 User Manual
Page 41
AT-GS950/48 Gigabit Ethernet WebSmart Switch Installation Guide
41
4. Mount the switch on a 19-inch rack, as shown in Figure 10.
Note
The rack mount screws are not provided.
Figure 10. Mounting the Switch on the Rack
5. If you plan to install SFP transceiver modules, go to the next step at
“Installing an SFP Transceiver” on page 42. Otherwise, your next step
will be “Cabling and Powering On the Switch” on page 44.
