Chapter 2: Installation
36
Installing the Switch on a Wall
The AT-GS950/48 Gigabit Ethernet Smart switch can be mounted
vertically on a wall using the two mounting brackets, screws, and anchors
provided in the accessory kit.
Note
The plastic anchors used for wall mounting the switch are intended
for installation in walls made of sheetrock or concrete materials.
To wall-mount the switch, perform the following procedure:
1. Place the unit on a level, secure surface.
2. Attach a mounting bracket to one side of the switch using four Phillips
head screws that come with the switch, as shown in Figure 6.
Figure 6. Attaching Brackets for Wall Mounting
3. Install the second mounting bracket on the other side of the switch
using the four remaining Phillips head screws.
