Front and back panels, Figure 1. at-gs950/48 front and back panels – Allied Telesis AT-GS950/48 User Manual
Page 19
AT-GS950/48 Gigabit Ethernet WebSmart Switch Installation Guide
19
Front and Back Panels
Figure 1 illustrates the front and back panels of the AT-GS950/48 Gigabit
Ethernet Smart switch.
Figure 1. AT-GS950/48 Front and Back Panels
1743
1744
100-240VAC~
50-60Hz
SFP Ports
10/100/1000Base Twisted Pair Ports
AC Power
System LEDs
eco-friendly Switch
System LEDs
