AT-GS950/48 Gigabit Ethernet WebSmart Switch Installation Guide
21
Eco-friendly Switch
The eco-friendly switch on the front panel is multifunctional and shown in
Figure 2. It may be used to conserve power by turning off the port LEDs,
reset the switch, or reset the switch configuration to the factory default
settings. The switch functions are described in Table 2.
Figure 2. Eco-friendly Switch
1745
Table 2. Eco-friendly Switch Functions
Action Results
Momentarily press the
switch. Enable or disable all front panel LEDs with the
exception of the POWER LED which remains
active at all times.
Hold the switch down for
more than 5 seconds, but
less than 10 seconds. Reset the switch.
Hold the switch down for
more than 10 seconds. Reset the switch and reset the configuration to
the factory default settings.
