Figure 23: installing the bottom vent cover – Allied Telesis AT-SBx3106WMB User Manual
Page 41
AT-SBx3106WMB Wall Mounting Brackets Installation Guide
41
3. Slide the second vent cover over the bottom vents. The tabs on the
cover fit into the slots on the bracket. Refer to Figure 23.
Figure 23. Installing the Bottom Vent Cover
Tabs
Slots
