AT-SBx3106WMB Wall Mounting Brackets Installation Guide
13
Required Tools
This section lists the tools necessary for installing the chassis on a wall
with the provided screws.
Concrete Wall The brackets come with hex-washer head lag screws for a concrete wall.
The screws are blue and have the following specifications:
 Length: 1 3/4 in.
 Diameter: 1/4 in.
 Hex size: 5/16 in.
 Quantity: 4
The following tools are required to install the chassis on a concrete wall
with the provided screws:
 Hammer drill
 3/16” carbide drill bit
 5/16” socket or wrench
Wallboard The brackets come with hex-washer head lag screws for a wallboard wall.
The screws are silver and have the following specifications:
 Length: 2 1/2 in.
 Diameter: 1/4 in.
 Hex size: 3/8 in.
 Quantity: 4
The following tools are required to install the chassis on wallboard with the
provided screws:
 3/8” socket or wrench
 3/16” drill bit
 Stud finder capable of identifying the middle of studs and hot
electrical wiring
Caution
The supplied screws may not be appropriate for all concrete or
wallboard walls. A qualified building contractor should determine the
appropriate hardware requirements for the wall prior to installing the
chassis.
