AT-SBx3106 Chassis and AT-SBx3106WMB Brackets
Figure 1 illustrates the AT-SBx3106 Chassis as it looks on the wall with
the AT-SBx3106WMB Wall Mounting Brackets.
Caution
The chassis must be installed on the wall in the orientation shown in
Figure 1. The fan module must be on top and the slot openings for
the line cards and power supplies must be on the right. The chassis
may experience inadequate ventilation and may overheat and fail if
it is installed on the wall in a different position than the one shown in
the figure.
Figure 1. AT-SBx3106 Chassis Switch with the AT-SBx3106WMB Wall
Mounting Brackets
Fan
Module
