AT-SBx3106WMB Wall Mounting Brackets Installation Guide
39
Installing the Vent Covers
To install the vent covers, perform the following procedure:
1. Slide one of the vent covers that come with the brackets over the top
vents of the chassis. The tabs on the cover fit into the slots on the
bracket. Refer to Figure 21.
Figure 21. Installing the Top Vent Cover
Tabs
Slots
