AT-SBx3106WMB Wall Mounting Brackets Installation Guide

35

Installing the Chassis on the Wall

To install the chassis on the wall, perform the following procedure:

Warning
The chassis is heavy. You might injure yourself or damage the
equipment if you attempt to perform this procedure alone. Allied
Telesis recommends a minimum of three people for the procedure.
Two people should lift the chassis and another person should secure
it with the bracket screws.

1. Have two people lift the chassis onto the screws on the wall. Refer to

Figure 17.

Figure 17. Placing the Chassis on the Wall
