Installation Instructions
The following instructions explain how to install the AT-SBx3106 Chassis
on a wall with the AT-SBx3106WMB Wall Mounting Brackets. The
instructions contain the following sections:
 “AT-SBx3106 Chassis and AT-SBx3106WMB Brackets” on page 12
 “Required Tools” on page 13
 “Selecting a Wall Location” on page 14
 “Reviewing Safety Precautions” on page 20
 “Checking the Components of the AT-SBx3106WMB Brackets” on
page 25
 “Marking the Wall Locations for the Screw Holes” on page 26
 “Installing the Screws in the Wall” on page 30
 “Installing the Brackets on the Chassis” on page 32
 “Installing the Chassis on the Wall” on page 35
 “Installing the Vent Covers” on page 39
Warning
THE CHASSIS MUST BE INSTALLED BY A
QUALIFIED BUILDING CONTRACTOR. SERIOUS
INJURY OR DEATH MAY RESULT IF THE CHASSIS IS
NOT PROPERLY SECURED TO THE WALL.
