Front and back panels – Allied Telesis x310 Series User Manual
Page 19
x310 Series Installation Guide for VCStack
19
Front and Back Panels
The front panels of the x310 Series switches are shown in Figure 1 here
and Figure 2 on page 20.
Figure 1. Front Panels of the AT-x310-26FT and AT-x310-26FP Switches
10/100Base-TX Ports
10/100/1000Base-T Ports
SFP Slots
Stacking Slots
Management Panel
AT-x310-26FT
10/100Base-TX Ports with PoE
10/100/1000Base-T Ports
SFP Slots
Stacking Slots
Management Panel
AT-x310-26FP
