Chapter 1: Overview
AT-IE200 Series Installation Guide 24
Maximum Distance
The ports have a maximum operating distance of 100 meters (328 feet).
Power Over Ethernet
The 10/100/1000Base-T ports on the AT-IE200-6GP switch support Power over Ethernet (PoE), which is a
standard whereby DC power is provided by the switch to network devices over the network twisted pair
cables. The switches support PoE (IEEE 802.3af) and PoE+ (IEEE 802.3at). For more information, refer to
“Power Over Ethernet” on page 26.
Cable Requirements
The cable requirements of the ports are given inTable 2.
Port Pinouts
Refer to Table 18 on page 69 for the port pinouts of the 10/100/1000Base-T twisted pair ports.
Table 2: Twisted Pair Cable Requirements for the 10/100/1000Base-T Ports
Cable Type 10Mbps 100Mbps 1000Mbps
Standard TIA/EIA 568-B-compliant
Category 3 shielded or unshielded
cabling with 100 ohm impedance
and a frequency of 16 MHz. Yes Yes No
Standard TIA/EIA 568-A-compliant
Category 5 or TIA/EIA 568-B-
compliant Enhanced Category 5
(Cat 5e) shielded or unshielded
cabling with 100 ohm impedance
and a frequency of 100 MHz. Yes Yes Yes
Standard TIA/EIA 568-B-compliant
Category 6 or 6a shielded cabling. Yes Yes Yes
