61
Appendix A
Technical Specifications
Below are the technical specifications for the AT-GS950/10PS,
AT-GS950/16PS and AT-GS950/48PS switches. The specification
categories are as follows:

“Physical Specifications” on page 61

“Environmental Specifications” on page 62

“Power Specifications” on page 62

“PoE Specifications” on page 62

“Safety and Electromagnetic Emissions Certifications” on page 63

“Connectors and Port Pinouts” on page 63
Physical Specifications
Dimensions
Weight
Table 10. Chassis Dimensions
Model W x D x H mm (in)
AT-GS950/10PS 330 mm x 200 mm x 44 mm
(13.0 in x 7.9 in x 1.7 in)
AT-GS950/16PS 440 mm x 250 mm x 44 mm
(17.3 in x 9.4 in x 1.7 in)
AT-GS950/48PS 440 mm x 430 mm x 44 mm
(17.3 in x 17.0 in x 1.7 in)
Table 11. Chassis Weight
Model Weight kg (lbs)
AT-GS950/10PS 1.90 kg (4.20 lbs)
AT-GS950/16PS 3.56 kg (7.85 lbs)
AT-GS950/48PS 6.62 kg (14.60 lbs)
