Page 19
AT-GS950/10PS, AT-GS950/16PS, and AT-GS950/48PS Switches Installation Guide
19
See Figure 2 for an example of the AT-GS950/10PS back panel.
Figure 2. AT-GS950/10PS Back Panel
See Figure 3 for an example of the AT-GS950/16PS back panel.
Figure 3. AT-GS950/16PS Back Panel
See Figure 4 for an example of the AT-GS950/48PS back panel.
Figure 4. AT-GS950/48PS Back Panel
AC Input
AC Input
AC Input
