GigaX Series L3 Managed Switch User Guide
55
4.6.10 Default Port VLAN and CoS
Some VLAN tag related field settings for each port are included in this page.
It includes:
Port: select the port to configure
PVID: port-based VLAN ID. Every untagged packet received from this
port will be tagged with this VLAN group ID
CoS (Class of Service) value: every untagged packet received from
this port will be assigned to this CoS in the VLAN tagged
Click on to change the content in the port list window. Click on
to save the configuration. To make the configuration effective, go
to “Save Configuration” page, then click .
Figure 29. Default Port VLAN and CoS
