GigaX Series L3 Managed Switch User Guide
49
Figure 24. IGMP Snooping
4.6.6 Traffic Control
Traffic control prevents the switch bandwidth from flooding packets
including broadcast packets, multicast packets and the unicast packets
because of destination address lookup failure. The limit number is a
threshold to limit the total number of the checked type packets. For
example, if broadcast and multicast are enabled, the total traffic amount for
those two types will not exceed the limit value. Click to save the
new configuration. To make the configuration effective, go to “Save
Configuration” page, then click .
