Rainwatch, Inst tion alla, Wall – Maximum Wireless Rainwatch (pre-2012) User Manual
Page 4

CABLE-HOLE
CABLES
SCREW
WOOD
PANEL
WALL
11
SCREW
RECEIVER
12 VOLT
POWER
SUPPLY
Mount the RAINWATCH indicator directly over the cable hole that is also used
to route power to the instrument. For the cleanest installation, we recommend
making a hole in the wall large enough to insert the wireless receiver. We also
recommend mounting the brass meter to one of our pre-drilled mounting panels.
HOLE
30 Barnet Boulevard
New Bedford, MA 02745
(508) 995-2200
Page 4
RAINWATCH
INST
TION
ALLA
WIRELESS
