NL200/201 Network Link Interface
8.1.1 Configuring the NL200/201
•
Connect to the NL200/201 in DevConfig (see Section 6, Configuring the
NL200/201).
•
On the NL200 tab:
o Set Bridge Mode to disable.
o Set Use DHCP to disable.
o Input the IP Address, Network Mask, and Default Gateway. These
values can be provided by your network administrator.
•
On the Network Services tab:
o Make note of the PakBus/TCP Server Port.
8.1.2 Configuring the Datalogger
The datalogger must first be configured for internet
communication (i.e., through an NL115, an NL120, a second
NL200/201, or a cellular modem).
•
Connect a serial cable from the PC COM port to the datalogger’s RS-232
port.
•
Open DevConfig. Select the device type of the datalogger (CR800,
CR1000, or CR3000), the appropriate
Communication Port, and Baud
Rate. Press Connect to connect to the datalogger.
•
On the Network Services tab:
o Under PakBus TCP Client Connections, input the NL200/201’s IP
address and PakBus TCP Server Port.
•
Press
Apply to save the changes and then close DevConfig.
9. Troubleshooting
This section covers some common problems that might be encountered when
using the NL200/201. This is not comprehensive but should provide some
insight and ability to correct simple errors without a call to Campbell Scientific
technical support.
When your Campbell Scientific software cannot establish a link to a remote
datalogger that is connected to the NL200/201, do the following:
1. Check all your power connections.
•
Your NL200/201 and any hub and/or router being used must be
connected to power. Check power indicator lights to make sure your
devices are powered.
NOTE
