Appendix A. Door Switch

A.2 Example Programs

A.2.1 CRBasic

'Program name: DOOR SWITCH CR1000.CR1
'Date written: 11/7/2005
'

' Door Switch Wiring
' +5V black - power to door switch
' C1 black - signal to control port 3


'\\\\\\\\\\\\\\\\\\\\\\\\\ DECLARATIONS /////////////////////////
Public DOOR_open_1

Public DOOR_output

'\\\\\\\\\\\\\\\\\\\\\\\\ OUTPUT SECTION ////////////////////////

DataTable(Table101,true,-1)
OpenInterval

DataInterval(0,5,Min,10)
Sample(1, DOOR_output, FP2)
EndTable


DataTable(Table102,true,-1)
OpenInterval

DataInterval(0,5,Min,10)
Histogram(DOOR_open_1, FP2, 0, 1,001, 1 , 0.5, 1.5)
EndTable


'\\\\\\\\\\\\\\\\\\\\\\\\\\\ PROGRAM ////////////////////////////
BeginProg

Scan(1,Sec, 3, 0)
' Configure control ports as inputs or outputs

PortsConfig (&B11111111,&B00000000)

' Measure Door switch

' (0=low=closed, 1=high=open)
If CheckPort(1) = true then
DOOR_open_1 = 1

Else
DOOR_open_1 = 0
EndIf


' Two of many possible methods to output the status of the door open switch

' - assumes 5 minute data:

' Method #1: If the door is open even one reading during the output interval,

' output a 1 for the Door variable
' If (DOOR_open_1 = 1)
Then

DOOR_output = 1
EndIf
CallTable Table101

' Reset door status after output interval
If TimeInToInterval(0,5,Min) Then
DOOR_output = 0

EndIf

' Method #2: Door open status may be recorded as a fraction of the output
' interval (between 0 and 1) using the Histogram instruction.
CallTable Table102


NextScan
EndProg

A-5
