DTE Options for Asynchronous and Synchronous Operation
The DTE options are configured separately for both DTE#1 and
DTE#2. When using the front panel, select the appropriate DTE
with either arrow key and press Enter. (See Figure 6-16 and 6-17.)
When using the VT 100 terminal select the option number corre-
sponding to the appropriate DTE and press Return.
Ensure the DTE equipment is set for asynchronous operation before at-
tempting to make an asynchronous call. Failure to do so causes the call
attempt to fail.
Figure 6-16
Asynchronous DTE Options Menu Tree
Figure 6-17
Synchronous DTE Options Menu Tree
3=CONFIG
1=Netw. options
2=DTE options
3=Protocol
4=Quick setup
5=Security
6=Remote Config
1=Bit Rate
2=Connector Type
3=RTS Options
4=CTS Options
5=CD Options
6=DTR Options
7=DSR Options
8=Flow Control
9=Data Format
1=Asynchronous
2=Synchronous
3=CONFIG
1=Netw. options
2=DTE options
3=Protocol
4=Quick setup
5=Security
6=Remote Config
1=Bit Rate
2=Connector Type
3=RTS Options
4=CTS Options
5=CD Options
6=DTR Options
7=DSR Options
8=Transmit Clock
1=Asynchronous
2=Synchronous
