Appendix D: S-Register List
110 ISU 2x64 Dual Port ISDN Service Unit User Manual 61200051L1-1D
S6.........DTR DIAL DELAY Delay time in minutes between consecutive outgoing
calls when DTR is set for Dial #0 if on option.
S7.........CONNECT TIME Determines how long the ISU 2x64 waits for an out-
going call to be answered.
15 = 15 seconds
30 = 30 seconds (default)
60 = 1 minute
120 = 2 minutes
240 = 4 minutes
S9 .........CLEAR CHAN DELAY The value multiplied by eight determines the number
of bytes between receive data and transmit data.
S10 .......DISABLE REMOTE Disables the two-second delay at the beginning of
CONFIG each incoming call that scans for remote configuration
data. FALLBACK protocol cannot be used when this option
is set!
0 = Remote Config enabled
1 = Remote Config disabled
S12 .......ESCAPE TIME Determines the delay required immediately before
and after entering the escape command for the ISU
2x64 to recognize and execute the command.
Range = 0 to 127 (default = 1 second)
S14 .......MISC BITS Miscellaneous bits (bit 8 is most significant bit) .
Bit 2 = 1:enables on screen echo of AT commands.
Bit 2 = 0: disables on screen echo of AT commands.
Bit 3 = 0: enables AT responses from the ISU 2x64.
Bit 3 = 1: disables AT responses from the ISU 2x64.
Bit 4 = 1: enables AT responses to be displayed
in text form.
Bit 4 = 0: enables AT responses to be displayed in nu-
meric form.
S15.........ASYNC BONDING REV Determines the revision level Bonding negotiates
for asynchronous connections.
0 = ADTRAN orginal Async. Bonding
1 = Multivendor Async. Bonding (default)
