Appendix D: S-Register List

61200051L1-1D

ISU 2x64 Dual Port ISDN Service Unit User Manual

117

S74.......DTE STOP

Selects the number of asynchronous stop bits. More
than one option can be set at the same time.
0 = 1 stop bit (default)
1 = 1.5 stop bits
2 = 2 stop bits

S75.......DTE FLOW

Selects asynchronous flow control
0 = None (default)
1 = Hardware flow. CTS from DCE controls DTE.
2 = Hardware flow. RTS from DTE controls DCE.
3 = Hardware flow. RTS and CTS flow control.
4 = Software flow. XON/XOFF from DCE controls
DTE.
8 = Software flow. XON/XOFF from DTE controls
DCE.
12 = Software flow. XON/XOFF controls DTE and
DCE.

S76.......DTE CLOCK

Selects DTE connector transmit clock timing source.
0 = Internal (ISU 2x64 supplies timing) (default)
1 = External (DTE supplies timing)

S135.....

Value determines whether or not the ISDN switch
should consider a DTE port busy. S23 must be pro-
grammed before this register is used.
0 = DTE port is not busy (default)
1 = DTE port is busy

The following are the string locations for stored numbers 0 - 9:

SS80.....SN0 LOC

Stored number 0 string

SS81.....SN1 LOC

Stored number 1 string

SS82.....SN2 LOC

Stored number 2 string

SS83.....SN3 LOC

Stored number 3 string

SS84.....SN4 LOC

Stored number 4 string

SS85.....SN5 LOC

Stored number 5 string

SS86.....SN6 LOC

Stored number 6 string

SS87.....SN7 LOC

Stored number 7 string

SS88.....SN8 LOC

Stored number 8 string

SS89.....SN9 LOC

Stored number 9 string

S118 = 0

CHAP Authentication (default)

S118 =32

PAP Authentication (required for MP connection with
WIN 95)
