61 - TreadMaster Information and Operating Instructions
EN
Figure 40. Housing Support Assembly
100-100-158 Rev. A
5
2X
3
2X
2
4
2X
1
SCREWS FASTEN AGAINST
THE OUTSIDE OF TANK 000-159-102
Housing Support Assembly Parts List
Item Part Number
Description
Qty
1
000-015-330
Bracket, Housing Support - Fabricated
1
2
000-015-322
Bracket, Housing Support - Fabricated
1
3
000-094-009
Nut, 1/4”-20UNC Nylock
2
4
000-094-034
Nut, #10-24UNC Nylock
2
5
000-143-062
Screw, #10-24UNC X 0.75” Lg. PPH
2
