TreadMaster Information and Operating Instructions - 46
EN
22” Nylon Grit Head Assembly
Item Part Number Description Qty Item Part Number Description Qty
1 105-100-024 Assembly Vac Nozzle-22” 1
2 000-015-331 Bracket, 19.5” Polish Pad Mounting Extrusion - Coated 1
3 000-015-332 Bracket 22” Tread Brush Mount-Coated 1
4 101-100-035 Brush Nylo-Grit-19.5” 1
5 000-016-081 Brush Vacuum-22” 1
6 000-033-102 Clamp, Polish Pad Release - Modified 2
7 000-074-022 Gauge,Spirit Level-TreadMaster 1
8 000-061-104 Handle, Pad Holder Lift Arm - Coated 1
9 000-061-102 Knob, 4/Flute Black-3/8”16 2
10 000-094-034 Nut, #10-24UNC Nylock 4
11 000-094-063 Nut, #6-32UNC Nylock 5
12 000-016-085 Polishing Pad-Black 1
13 000-143-062 Screw, #10-24 UNC . X 0.75” Lg. PH Phillips 4
14 000-143-047 Screw, #6-32 UNC X .875” Lg. PH Phillips 5
15 000-143-173 Screw, 1/4-20 Spade Head Thumb 1
16 000-143-112 Screw, 10-24 X 1/2” Self Tapping PH Phillips 3
17 000-143-128 Screw, 10-24 X 5/8” Btn Hd Cap 8
18 000-143-161 Screw, 5/16-18 X 1” PH Phillips 2
19 000-154-001 Spacer, 1/4” X 5/16” - S/S Solution Valve 5
20 000-156-019 Stud 3/8-16 X 2 1/2” 2
21 000-174-003 Washer, 1/4” Flat 3
22 000-174-059 Washer,5 /16” S/S External Star 2
