CONFIGURATIONS
Table 1. TreadMaster Configurations - 120V
TreadMaster
Top Level P/N
Major Assemblies in Top Level P/N
P/N
Description
Qty
22” TreadMaster, 120 V
100-100-004
101-100-031 24”
Soft Brush for Painted Escalators 1
190-100-002
120 V Housing Assembly
1
190-100-014
22” Nylon Grit Head Assembly
1
24” TreadMaster, 120 V
100-100-001
101-100-031 24”
Soft Brush for Painted Escalators 1
190-100-002
120 V Housing Assembly
1
190-100-011
24” Nylon Grit Head Assembly
1
32” TreadMaster, 120 V
100-100-002
101-100-032 32”
Soft Brush for Painted Escalators 1
190-100-002
120 V Housing Assembly
1
190-100-012
32” Nylon Grit Head Assembly
1
37” TreadMaster, 120 V
100-100-005
101-100-033 40”
Soft Brush for Painted Escalators 1
190-100-002
120 V Housing Assembly
1
190-100-015
37” Nylon Grit Head Assembly
1
40” TreadMaster, 120 V
100-100-003
101-100-033 40”
Soft Brush for Painted Escalators 1
190-100-002
120 V Housing Assembly
1
190-100-013
40” Nylon Grit Head Assembly
1
Table 2. TreadMaster Configurations - 230V
TreadMaster
Top Level P/N
Major Assemblies in Top Level P/N
P/N
Description
Qty
24” TreadMaster, 230 V
100-100-221
101-100-031 24”
Soft Brush for Painted Escalators 1
190-100-011
24” Nylon Grit Head Assembly
1
190-100-201
230 V Housing Assembly
1
32” TreadMaster, 230 V
100-100-222
101-100-032 32”
Soft Brush for Painted Escalators 1
190-100-012
32” Nylon Grit Head Assembly
1
190-100-201
230 V Housing Assembly
1
40” TreadMaster, 230 V
100-100-223
101-100-033 40”
Soft Brush for Painted Escalators 1
190-100-013
40” Nylon Grit Head Assembly
1
190-100-201
230 V Housing Assembly
1
