TreadMaster Information and Operating Instructions - 54
EN
Figure 34. Right Extension Arm Assembly
100-100-153 Rev. A
Right Extension Arm Assembly Parts List
Item Part Number Description Qty
1 000-015-321 Bracket, 16” Extension Arm - Coated 1
2 000-015-320 Bracket, Sliding - Coated 1
3 000-103-053 Pin, Release Pin 1
4 000-108-104 Protector, 3” Extension Arm Bumper Pad 1
5 000-108-105 Protector, 5” Extension Arm Bumper Pad 1
6 000-143-058 Screw,#8 Tek X 3/4” Lg. 7
