TreadMaster Information and Operating Instructions - 22

OPERATION

1. To seat the cleaning brush in the grooves, set the polishing pad holder lift arm in the

"up" position (see Figure 16).

2. Attach the warning sign to the crossbar handle (see Figure 13).
3. Plug in the power cord at the machine receptacle first; then, plug the cord into the

nearest rated outlet.

4. Prior to starting the escalator/moving sidewalk, review Steps 2 – 11 on pages

19 – 21.

5. Turn on the TreadMaster’s power switch (see Figure 12).
6. Turn on the escalator and again make sure the direction of travel is away from the

TreadMaster.

For first-time cleaning, U.S. Products recommends that the unit be allowed to run

for 1 hour for optimum results.

Polishing Pad

Holder Lift Arm

Figure 16. Set Lift Arm in Up Position
