59 - TreadMaster Information and Operating Instructions
EN
Figure 38. Door Assembly
100-100-156 Rev. A
See Figure 23 for adhesive/sealant information.
Door Assembly Parts List
Item Part Number Description Qty
1 000-067-017 Hinge Set, Left 1
2 000-067-018 Hinge Set, Right 1
3 000-086-107 Latch 1
4 000-094-034 Nut, #10-24UNC Nylock 2
5 000-100-054 Panel, Vacuum Access Door - Coated 1
6 000-143-061 Screw, #10-24 UNC X 0.50” Lg. PPH 4
7 000-143-114 Screw, #10-24UNC X 0.50” Lg. Flat Head Phillips 4
8 000-143-110 Screw, #10-24UNC X 5/8” Lg. Flat Head 2
