U.S. Products TREADMASTER - Manual (Page 54)

TreadMaster Information and Operating Instructions - 48
EN
37” Nylon Grit Head Assembly
Item Part Number Description Qty Item Part Number Description Qty
1 105-100-022 Assembly Vacuum Nozzle-37” 1
2 000-015-351 Bracket 37” Tread Brush Mount-Coated 1
3 000-015-340 Bracket, 34” Polish Pad Mounting Extrusion - Coated 1
4 101-100-037 Brush Nylo-Grit-19.5” 1
5 000-016-083 Brush Vacuum-37” 1
6 000-033-102 Clamp, Polish Pad Release - Modified 2
7 000-074-022 Gauge,Spirit Level-TreadMaster 1
8 000-061-104 Handle, Pad Holder Lift Arm - Coated 1
9 000-061-102 Knob,4/Flute Black-3/8”16 2
10 000-094-034 Nut, #10-24UNC Nylock 4
11 000-094-063 Nut, #6-32UNC Nylock 7
12 000-016-089 Polishing Pad-Black 1
13 000-143-062 Screw, #10-24 UNC X 0.75” Lg. PH Phillips 4
14 000-143-047 Screw, #6-32 UNC X .875” Lg. PH Phillips 7
15 000-143-173 Screw, 1/4-20 Spade Head Thumb 1
16 000-143-112 Screw, 10-24 X 1/2” Self Tapping PH Phillips 5
17 000-143-128 Screw, 10-24 X 5/8” Btn Hd Cap 8
18 000-143-161 Screw,5/16-18 X 1” PH Phillips 2
19 000-154-001 Spacer, 1/4” X 5/16” - S/S Solution Valve 7
20 000-156-019 Stud 3/8-16 X 2 1/2” 2
21 000-174-003 Washer, 1/4” Flat 5
22 000-174-059 Washer, 5/16” S/S External Star 2
